326SWITCHGEAR & DISTRIBUTIONTogether we GENERATE VALUEEnclosed Surge Protection• IP54 metal enclosure• Retrofit solution• Ideal for any brand of consumer unitsurge safeSurge ProtectionMetal Clad Enclosures (IP40) Mersen Surge Protection• Suitable for TT, TN-S & TN-C-S (PME)• Din rail mountable, plug-in format • Visual & remote end of life indicators • Reversible chassis for entry from above or below • Mechanically coded cartridges avoid replacement errorsPart No. DescriptionMEC2M 2 Module H: 146 W: 80 D: 62MEC3M 3 Module H: 105 W: 105 D: 78MEC4M 4 Module H: 238 W: 125 D: 78MEC6M 6 Module H: 248 W: 161 D: 78MEC4T * 4 Module H: 190 W: 115 D: 61Part No. Description83120115 2 Module Type 1/2 single phase TT/TN83120139 4 Module Type 1/2 three phase TT/TN83020117 2 Module Type 2 single phase TT/TN83020147 4 Module Type 2 three phase TT/TN83230511 2 Module Type 2 & 3 single phase TT/TN83230129 4 Module Type 2 & 3 three phase TT/TNPart No. DescriptionECSS-101 With TT/TN type 2 SPD + 2P main switchECSS-102 With TT/TN type 2 SPD & 32A MCBMetal Clad Garage Units (IP54) Dehn Surge ProtectionPart No. DescriptionGRG16MA 63A Type A RCCB + 6A & 16A MCBGRG32MA 63A Type A RCCB + 6A & 32A MCBPart No. Description941110 2 Module Type 1/2 Single Phase TT/TN941310 4 Module Type 1/2 Three Phase TT/TN951115 4 Module Type 1/2 Single Phase TT/TN951310 8 Module Type 1/2 Three Phase TT/TN952110 2 Module Type 2 Single Phase TT/TN952315 4 Module Type 2 Three Phase TT/TN100A Metal Clad Switch Fuses (IP54)• 100A 230V single phase switch fuse • 5 module metal clad enclosure• Incoming terminal capacity 2.5 to 25mm2• 4 x M20, 2 x 25mm cable entries• Free pack of 3 fuses includedPart No. DescriptionSPSF100M-F 100A Switch FuseEnclosed Surge Protection• Retrofit solution (with DEHN SPD)• Ideal for any brand of consumer unitPart No. DescriptionECSS-301D TT/TN 3 Phase Type 2 SPD W/ 63A MCBECSS-302D TT/TN 3 Phase Type 2 SPD W/ 63A MCBEnclosed Surge Protection• IP67 enclosure• Retrofit solution • Ideal for any brand of consumer unitPart No. DescriptionECSS-3101D TT/TN 3 Phase Type 1/2 SPD + 160A FusesECSS-3101M TT/TN 3 Phase Type 1/2 SPD + 160A FusesECSS-301DIP65 ABS EnclosureECSS-302DIP54 Metal EnclosureECSS-3101D | DEHN SPD ECSS-3101M | Mersen SPDTOPRATED• For lightning protection systems with lightning protection levels 3 or 4 up to 12.5kA or for an overhead supply line• For domestic, commercial & light industrial applications typically up to 125A• RAL 7035• EN 60898 & EN 61008 compliant• All MCBs are single pole B curve 6kA• Earth & neutral terminals included• Dimensions: H: 240 x W: 160 x D: 85mm• Modular Metal Clad Enclosures • Amendment 3 Compliant Enclosures• Complete with Earth Terminal & Din Rail• MEC4T suitable for consumer unit tails
