323SWITCHGEAR & DISTRIBUTIONTogether we GENERATE VALUEDistribution Equipment & Circuit ProtectionCompact Garage UnitMain Switch Boards• 100A main switch incomer• + 2 BlanksDual RCCB + MCB Fully Loaded• 100A main switch • + 2 80A RCCBs Type A • + MCBs (6A, 16A, 32A, 40A) + BlankssentinelDual RCCB Boards• 100A main switch• + 2 80A RCCBs Type A• + 2 BlanksPart No. DescriptionSLCU16DS-FL01 16 (10 Useable) Ways (2x6A, 2x16A, 3x32A, 1x40A) MCBsSLCU20DS-FL01 20 (14 Useable) Ways(3x6A, 2x16A, 4x32A, 1x40A) MCBsSLCU18DS-SPD-FL01 Type 2 SPD 18 (10 Useable) Ways(2x6A, 2x16A, 3x32A, 1x40A) MCBsSLCU20DS-SPD-FL01 Type 2 SPD20 (12 Useable) Ways(3x6A, 2x16A, 4x32A, 1x40A) MCBs Part No. DescriptionSLCU14DS 14 (8 Useable) WaysSLCU16DS 16 (10 Useable) WaysSLCU18DS 18 (12 Useable) WaysSLCU20DS 20 (14 Useable) WaysSLCU24DS-DT 24 (18 Useable) WaysSLCU36DS-DT 36 (30 Useable) WaysPart No. DescriptionGRGC16M 63A RCCB Type A + 6A & 16A MCBSentinelby EUR PASPD Options AvailableSentinel Lockable LidsPart No. DescriptionSLCU6LL Lockable lid for 6 Way BoardSLCU8LL Lockable lid for 8 Way BoardSLCU10LL Lockable lid for 10 Way BoardSLCU12LL Lockable lid for 12 Way BoardSLCU14LL Lockable lid for 14 Way BoardSLCU16LL Lockable lid for 16 Way BoardSLCU18LL Lockable lid for 18 Way BoardSLCU20LL Lockable lid for 20 Way BoardSentinel AccessoriesPart No. DescriptionSLCUACC01KIT Accessory KitSLCUNC16280 Neutral Cable 16mm, 280mmSLCUBB-10 100A Busbar, 10 WaySLCUBB-14 100A Busbar, 14 WaySLCUBB-18 100A Busbar, 18 WaySLCUMMB Metal Module CoversSLCUSPD2KIT Type 2 SPD Kit w/ 32A MCB & WiresAUSP-40J/1+1 1 Mod. Sing. Phase Type 2M32CU25-16 Cable Gland, 25mm tailsSL-HSP Single Mod. 100A Type 2 SPD (no MCBs required)SLCU1MSPDKIT 1 Module SL-HSP T2 SPD with the cable setSentinel boards are for use with our 6kA MCBS (EUB1*B) & compact 6kA RCBOs (EUB1RC) | See the next page for part numbersRCCB BoardsPart No. Description No of waysSLCU6R 80A 2 Pole Type A RCCB 6 (4 Useable ways) SLCU8R 80A 2 Pole Type A RCCB 8 (6 Useable ways) SLCU10R 80A 2 Pole Type A RCCB 10 (8 Useable ways) SLCU12R 80A 2 Pole Type A RCCB 12 (10 Useable ways)SLCU14R 80A 2 Pole Type A RCCB 14 (12 Useable ways) SLCU20R 80A 2 Pole Type A RCCB 20 (18 Useable ways)Type 2 SPD optionSentinel Empty Consumer UnitsPart No. DescriptionSLCU6 6 WaysSLCU8 8 Ways SLCU10 10 WaysSLCU12 12 WaysSLCU14 14 WaysSLCU20 20 WaysSLCU24-DT 24 WaysSLCU36-DT 36 WaysPart No. DescriptionSLCU6M 6 (4 Useable) WaysSLCU8M 8 (6 Useable) WaysSLCU10M 10 (8 Useable) WaysSLCU12M 12 (10 Useable) WaysSLCU14M 14 (12 Useable) WaysSLCU16M 16 (14 Useable) WaysSLCU18M 18 (16 Useable) WaysSLCU20M 20 (18 Useable) WaysType 2 SPD Pre-Fitted OptionsSLCU8M-SPD (4 Useable Ways)SLCU6M-SPD 6 Ways (2 Useable)SLCU10M-SPD (6 Useable Ways)SLCU12M-SPD (8 Useable Ways)SLCU14M-SPD (10 Useable Ways)SLCU16M-SPD 16 Ways (12 Useable)SLCU18M-SPD 18 ways (14 Useable)SLCU20M-SPD (16 useable Ways)Dual Stack Main SwitchPart No. DescriptionSLCU24M-DT 24 (20 Useable) WaysSLCU36M-DT 36 (32 Useable) WaysDual Tarriff BoardsPart No. DescriptionSLCU18MM 18 (14 Useable) WaysSLCU20MM 20 (16 Useable) WaysSLCU24MM-DT 24 (20 Useable) WaysSLCU36MM-DT 36 (32Useable) WaysPart No. DescriptionSLCU6EV40A Type A RCCBSLCU6EV40A-SPD Type A RCCB + SPDSLCU6EV40B Type B RCCBSLCU6EV40B-SPD Type B RCCB + SPDEV Boards• 40A MCB
