P. 338

                    INDUSTRIAL CONTROLS
Motor Starters
Motor Starters
• DOL and Start Delta Starters
• Plastic Enclosure IP66 or Steel Enclosure IP55
• No Overload fitted
• Reversing DOL and Isolator Versions
Pushbutton Stations
    ABB
    Part No. Description
  1TVC230050P5699
  DOL 5.5KW 230V Plastic
 1TVC230070P5699
DOL 7.5KW 230V Plastic
 1TVC400050P5699
 DOL 5.5KW 400V Plastic
 1TVC400070P5699
 DOL 7.5KW 400V Plastic
 1TVC230050S5699
  DOL 5.5KW 230V Steel
 1TVC230070S5699
DOL 7.5KW 230V Steel
 1TVC400050S5699
 DOL 5.5KW 400V Steel
 1TVC400070S5699
 DOL 7.5KW 400V Steel
 1TVC230051S5699
 DOL+ISO 5.5KW 230V Steel
 1TVC230071S5699
  DOL+ISO 7.5KW 230V Steel
 1TVC400051S5699
DOL+ISO 5.5KW 400V Steel
 1TVC400071S5699
 DOL+ISO 7.5KW 400V Steel
 1TVC230072S5699
  DOLR 7.5KW 230V Steel
 1TVC400072S5699
DOLR 7.5KW 400V Steel
 1TVC230153S5699
 SD 15.0KW 230V Steel
 1TVC230223S5699
 SD 22.0KW 230V Steel
 1TVC400153S5699
  SD415S 15.0KW 400V Steel
 1TVC400223S5699
SD 22.0KW 400V Steel
 1TVC230154S5699
 SD+ISO 15.0KW 230V Steel
 1TVC230224S5699
 SD+ISO 22.0KW 230V Steel
 1TVC400154S5699
  SD+ISO 15.0KW 400V Steel
 1TVC400224S5699
 SD+ISO 22.0KW 400V Steel
     Part No. Description
  1TVC110000P3101
 1 Way Start Pushbutton / Green
 1TVC101000P3102
  1 Way Stop Pushbutton / Red
 1TVC101000P3203
Emergency Stop 30mm Twist Release
 1TVC101000P3204
 Emergency Stop 40mm Twist Release
 1TVC101000P3205
 Emergency Stop 60mm Twist Release
 1TVC101000P3206
 Emergency Stop 40mm Key Release
 1TVC110000P3107
  Two Position Switch
 1TVC110000P3108
 Two Position Key Switch
 1TVC110100P3109
Three Position Switch
 1TVC110100P3110 1TVC211000P3111
  Three Position Key Switch 2 Way Start / Stop
  1TVC211000P3112
  2 Way Start / E-Stop
    Overload for Motor Starters
• Thermal Overloads for Starters
• Note for Star Delta starters Overload setting
should be 0.58 x FLC
Contact Blocks
GENERATE VALUE
  Part No. Description
  1SAZ721201R1023
 Thermal Overload 0.74 ...1 A
 1SAZ721201R1025
  Thermal Overload 1 ...1.3 A
 1SAZ721201R1028
Thermal Overload 1.3 ...1.7 A
 1SAZ721201R1031
 Thermal Overload 1.7 ...2.3 A
 1SAZ721201R1033
 Thermal Overload 2.3 ...3.1 A
 1SAZ721201R1035
  Thermal Overload 3.1 ...4.2 A
 1SAZ721201R1038
Thermal Overload 4.2 ...5.7 A
 1SAZ721201R1040
 Thermal Overload 5.7 ...7.6 A
 1SAZ721201R1043
 Thermal Overload 7.6 ...10 A
 1SAZ721201R1045
 Thermal Overload 10 ...13 A
 1SAZ721201R1047
  Thermal Overload 13 ...16 A
 1SAZ721201R1049
Thermal Overload 16 ...20 A
 1SAZ721201R1051
 Thermal Overload 20 ...24 A
 1SAZ721201R1052
 Thermal Overload 24 ...29 A
 1SAZ721201R1053
  Thermal Overload 29 ...35 A
 1SAZ721201R1055
 Thermal Overload 35 ...38 A
      Part No. Description
  1SFA611610R2001
  Contact Block 1 Normally Open
 1SFA611610R2010
 Contact Block 1 Normally Closed
     338
