340SWITCHGEAR & DISTRIBUTIONTogether we GENERATE VALUEimoMotor Control GearIP65 Changeover Switches%u2022 Operating Voltage: 230-440VIP65 Enclosed Isolators%u2022 Operating Voltage: 230-440VEnclosure Base PlatesIP44 / IP56 EnclosuresPart No. Current Ie (AC21) Dimensions (h x w x d) PolesSCO4P20 20 Amps 175 x 115 x 100mm 4SCO4P32 32 Amps 175 x 115 x 100mm 4SCO4P40 40 Amps 175 x 115 x 100mm 4SCO4P63 63 Amps 240 x 160 x 120mm 4SCO4P80 80 Amps 240 x 160 x 120mm 4SCO4P100 100 Amps 240 x 160 x 120mm 4Part No. Current Ie (AC21) Dimensions (h x w x d) PolesIS4P20 20 Amps 125 x 100 x 85mm 4IS4P20L 20 Amps 175 x 115 x 100mm 4IS4P32 32 Amps 125 x 100 x 85mm 4IS4P32L 32 Amps 175 x 115 x 100mm 4IS4P40 40 Amps 175 x 115 x 100mm 4IS4P63 63 Amps 175 x 115 x 100mm 4IS4P80 80 Amps 240 x 160 x 120mm 4IS4P100 100 Amps 240 x 160 x 120mm 4IS4P125 125 Amps 240 x 160 x 120mm 4IS4P150 150 Amps 240 x 160 x 120mm 4Part No. Compatible Enclosure DimensionsSEBP07 For use with SE07 170 x 130mmSEBP08 For use with SE08 222 x 178mmSEBP09 For use with SE09 287 x 207mmSEBP10 For use with SE10 362 x 282mmPart No. Description Dimensions IP RatingSE02 Round (clip-on lid) %u00d880 x 40mm IP44SE03 Square (clip-on lid) 80 x 80 x 50mm IP44SE04 Square 100 x 100 x 50mm IP56SE05 Rectangular 120 x 80 x 50mm IP56SE06 Rectangular 150 x 110 x 70mm IP56SE07 Rectangular 190 x 140 x 70mm IP56SE08 Rectangular 240 x 190 x 90mm IP56SE09 Hinged Lid 300 x 220 x 120mm IP56SE010 Hinged Lid 380 x 300 x 120mm IP56Part No. DescriptionTB01C 10x 2.5mm Terminals + 10x MarkersTB02C 10x 4mm Terminals + 10x MarkersTB03C 5x 10mm Terminals + 10x MarkersTB04C 3x 16mm Terminals + 3x End + 10x MarkersTB05C 2x 35mm Terminals + 10x MarkersTB06C DIN Terminal Accessory Kit -2x End Plates (2.5-10mm),2x End Brackets, 2x Partition,2x 4mm Earth Terminals, 1x 4mmNeutral Terminals & 10x MarkersTB07C 3x Fuse Holders + 3x End PlatesTB08C 5x 4mm Blue Neutral TerminalsTB09C 5x 4mm Green/Yellow EarthTerminalsTB10C 3x 16mm Green/Yellow EarthTerminalsPart No. DescriptionEN11C Opaque 75x125x75mmEN12C Opaque 125x125x75mmEN13C Opaque 125x125x100mmEN14C Opaque 125x175x75mmEN15C Opaque 125x175x100mmEN16C Opaque 125x175x125mmEN17C Opaque 175x175x100mmEN18C Opaque 175x175x125mmEN19C Opaque 175x175x150mmEN20C Opaque 175x250x100mmEN21C Opaque 175x250x150mmEN23C Clear Lid 125x125x75mmEN24C Clear Lid 125x175x100mmEN25C Clear Lid 125x175x100mmPart No. DescriptionTB20C Enclosure c/w 5x4mm DIN Terminals+ 1x4mm Earth Terminals &End Stop 30ATB30C 88x88x53mm Enclosurec/w 5x2.5mm Terminals 20ATB31C 98x98x61mm Enclosurec/w 5x4mm Terminals 25ATB32C 119x139x70mm Enclosurec/w 5x6mm Terminals 32ADIN Rail Terminals IP66 Enclosures with DIN Rail IP65/55 Terminal Boxes
