345SWITCHGEAR & DISTRIBUTIONTogether we GENERATE VALUEFusesConsumer Unit Fuse-LinksPart No. Current Rating BS 1361Colour CodingPrincipal Dimensions(A) BS 1361 (A) BS 88 L (mm) L (ins) D (mm) D (ins)LA2 - 2 - 23 7/8 6.35 1/4LA5 5 - White 23 7/8 6.35 1/4LC2 - 2 - 26 1 10.32 13/32LC5 - 5 - 26 1 10.32 13/32LC8 - 8 - 26 1 10.32 13/32LC10 - 10 - 26 1 10.32 13/32LC15 15 16 Blue 26 1 10.32 13/32LC20 20 20 Yellow 26 1 10.32 13/32LD6 - 6 - 29 1 1/8 12.7 1/2LD10 - 10 - 29 1 1/8 12.7 1/2LD16 - 16 - 29 1 1/8 12.7 1/2LD20 - 20 - 29 1 1/8 12.7 1/2LD25 - 25 - 29 1 1/8 12.7 1/2LD30/32 30 32 Red 29 1 1/8 12.7 1/2LK35 - 35 - 35 1 3/4 16.67 1/32LK40 - 40 - 35 1 3/4 16.67 1/32LK45 - 45 Green 35 1 3/4 16.67 1/32• Lawson type L Fuse-Links are for use in household consumer units or other single phase installations with fault levels up to 16.SkA• They can be fitted into Pullcap Fuse-Holders or other suitable Fuse-Holders230/240 Consumer Unit Fuse-Links to IEC 60269-3/BS 88-3 and BS 1361Rated Voltage 240V a.c. Breaking Capacity 16.SkA a.c. Breaking Range and Utilisation Category gGNote: In addition to the current ratings specified in BS 1361, additional ratings certified to BS 88 have been included to meet other requirements.Together Better we areFegime does not aim to be the biggest but the best. A goal which drives members to consistently out perform the market average.
