                    INDUSTRIAL PLUGS & SOCKETS Switched Interlocked Sockets
Surface Mounted
Switched Interlocked Sockets
• Switched Interlocked units incorporate a mechanical interlock mechanism which prevent the switch from being turned ‘ON’ until the plug is fully inserted
• The plug cannot be withdrawn until the switch is turned to the ‘OFF’ position
• The switch can be padlocked in the ‘OFF’ position
IP44 Switched Interlocked Sockets
Surface Mounted RCD Protected
Switched Interlocked Sockets
• Switched Interlocked units incorporate a mechanical interlock mechanism which prevent the switch from being turned ‘ON’ until the plug is fully inserted
• The plug cannot be withdrawn until the switch is turned to the ‘OFF’ position
• The switch can be padlocked in the ‘OFF’ position
• Units are supplied with RCD (for earth fault protection) with sensitivity of
30mA as standard other mA ratings available upon request • All units are internally pre-wired, tested and inspected
IP44 RCD Protected Switched Interlocked Sockets
                Part No.
Amps
Voltage
Pins
Protection
880466
 16
 110
 3
 25a 30mA 2P RCD
 880468
 32
 110
 3
 40a 30mA 2P RCD
 880470
  63
  110
  3
  63a 30mA 2P RCD
  880448
16
230
3
25a 30mA 2P RCD
880450
 32
 230
 3
 40a 30mA 2P RCD
 880452
  63
  230
  3
  63a 30mA 2P RCD
  880454
16
400
4
25a 30mA 4P RCD
880456
 32
 400
 4
 40a 30mA 4P RCD
 880458
 63
 400
 4
 63a 30mA 4P RCD
 880460
  16
  400
  5
  25a 30mA 4P RCD
  880462
 32
 400
 5
 40a 30mA 4P RCD
 880464
 63
 400
 5
 63a 30mA 4P RCD
       Part No.
Amps
Voltage
Pins
16165
 16
 110
 3
 16191
  32
  110
  3
  16217
63
110
3
16167
 16
 230
 3
 16193
 32
 230
 3
 16219
  63
  230
  3
  16175
16
400
4
16201
 32
 400
 4
 16227
 63
 400
 4
 16185
  16
  400
  5
  16211
 32
 400
 5
 16237
 63
 400
 5
        IP67 RCD Protected Switched Interlocked Sockets
 Part No.
Amps
Voltage
Pins
Protection
880418
  16
  110
  3
  25a 30mA 2P RCD
  880422
32
110
3
40a 30mA 2P RCD
880426
 63
 110
 3
 63a 30mA 2P RCD
 880118
  16
  230
  3
  25a 30mA 2P RCD
  880122
32
230
3
40a 30mA 2P RCD
880126
 63
 230
 3
 63a 30mA 2P RCD
 880602
 125
 230
 3
 100a 30mA 2P RCD
 880604
  125
  230
  3
  125a 30mA 2P RCD
  880130
16
400
4
25a 30mA 4P RCD
880134
 32
 400
 4
 40a 30mA 4P RCD
 880138
 63
 400
 4
 63a 30mA 4P RCD
 880606
  125
  400
  4
  100a 30mA 4P RCD
  880142
16
400
5
25a 30mA 4P RCD
880146
 32
 400
 5
 40a 30mA 4P RCD
 880150
  63
  400
  5
  63a 30mA 4P RCD
  880610
125
400
5
100a 30mA 4P RCD
880608
  125
  400
  4
  125a 30mA 4P RCD
  880612
 125
 400
 5
 125a 30mA 4P RCD
     IP67 Switched Interlocked Sockets
 Part No.
Amps
Voltage
Pins
16166
 16
 110
 3
 16192
  32
  110
  3
  16218
63
110
3
16168
 16
 230
 3
 16194
 32
 230
 3
 16220
  63
  230
  3
  16176
16
400
4
16202
 32
 400
 4
 16228
  63
  400
  4
  1635
125
400
4
16186
 16
 400
 5
 16212
 32
 400
 5
 16238
  63
  400
  5
  169
 125
 400
 5
          348
