350SWITCHGEAR & DISTRIBUTIONTogether we GENERATE VALUEFusesIndustrial Fuse-Links with Bolted ConnectionsPart No. Current Rating BS88 ReferenceFixing CentresG1 (mm) G1 (ins) G2 (mm) G2 (ins)NIT 2, 4, 6, 10, 16, 20, 25, 32 A1 44.5 1 3/4 - -TIA 2, 4, 6, 10, 16, 20, 25, 32 A2 73 2 7/8 - -TIS 35, 40, 50, 63, 80, 100, 125 A3 73 2 7/8 - -TCP 6, 10, 16, 20, 25, 32, 40, 50, 63 ,80, 100 A4 94 3 11/16 - -CTFP 125, 160, 200 (as A4) 94 3 11/16 - -TFP 125, 160, 200 (as A4) 94 3 11/16 - --85TM 200, 250, 315, 355, 400 - 102 4 22 7/886TT 450, 500, 560, 630, 670, 710, 750, 800 - 102 4 22 7/8%u2022 Lawson Type %u201cN%u201d & %u201cT%u201d fuse-links are for use in industrial installations and can be fitted into 8S88 bolted fuse-holders and distribution fusegear%u2022 Dimensions and current ratings of the Lawson type N& T Industrial Fuse-Links comply with the standardized requirements of IEC 60269-2 and BS 88-2%u2022 Additional types and current ratings are included in the range%u2022 Lawson type N& T Industrial Fuse-Links can be fitted in Boltin Fuse-Holders400/415 Volt Industrial Fuse-links to IEC 60269-2/BS 88-2 Rated voltages: 41 SV a.c. 250V d.c. Breaking Capacities 80kA d.c. Breaking Ranges and Utilisation Category gG/gMPart No. Current Rating BS88 ReferenceFixing CentresG1 (mm) G1 (ins) G2 (mm) G2 (ins)TB 2, 4, 6, 10, 16, 20, 25, 32, 35, 40, 50, 63 - 97 3 13/16 - -TBC 2, 4, 6, 10, 16, 20, 25, 32, 35, 40, 50, 63 (as B1) 111 4 3/8 - -TC 80, 100 B1 111 4 3/8 - -TF 125, 160, 200 B2 111 4 3/8 - -84TF 80, 100, 125, 160, 200 - 99 3 29/32 - -TKF 250, 315 B3 111 4 3/8 - -84TK 250, 315 - 99 3 29/32 - -TKM 125, 160, 200, 250, 315 - 133 5 1/4 - -TMF 315, 355, 400 B4 111 3 11/16 - -TM 250, 315, 355, 400 C1 133 5 1/4 184 7 1/4TMT 355, 400 - 165 6 1/2 229 9TTM 450, 500, 560, 630 C2 133 5 1/4 184 7 1/4TT 450, 500, 560, 630 - 165 6 1/2 229 9TLM 670, 710, 750, 800 C3 133 5 1/4 184 7 1/4TLT 670, 710, 750, 800 - 165 6 1/2 229 9TLU 450, 500, 560, 630, 670, 710, 750, 800 D1 149 5 1/4 32 1 1/4
