356SWITCHGEAR & DISTRIBUTIONTogether we GENERATE VALUEPanel BoardsPanel BoardsPowerpact 4 Panel BoardsThe range of wall and floor mounted Powerpact 4 panelboards is designed, manufactured and tested to BS EN 61439-1. The structures are rigid sheet steel finished in a cream colour epoxy powder (RAL 9001).All the boards contain a unique connection system which ensures that all busbar/breaker connections are tightened to the correct torque. The system comprises atightening bolt head which shears off when the correct torque is reached. Facilities are provided to enable the breaker to be repositioned at a later time if so required.The breaker range comprises single pole, single pole with switched neutral, double pole, triple pole and three pole with switched neutral and four pole. Incoming device ratings up to 1600A and outgoing ratings up to 630A.The extremely flexible board design allows 1, 2, 3 and 4 pole breakers to be positioned in any order on the busbar stack thus allowing maximum use of the available space and also allowing breakers feeding associated loads to be positioned together.Technical CharacteristicsRatings Up to 1600AIP Rating IP3XShort Circuit Rating up to 50kAPowerpact 4 Panel BoardsPart No. SP Outgoing WaysTP Outgoing WaysMG2C5 15 5MG2C7 21 7MG2C9 27 9MG2C13 39 13Wall mounted Powerpact 4 panel boards are ideally suited to installations where space is restricted or where only a small number of outgoing circuits are required. The main incomer is side mounted at the bottom right and will accommodate up to 13TP outgoing ways.Incoming Devices up to 250APart No. Description RatingPP42503X 3P MCCB 250A 36kAPP42504X 4P MCCB 250A 36kAPP42503NAX 3P Switch Disconnector250APowerpact 4 400A/630A Panel BoardsWall mounted Panel Boards with top or bottom entry for greater flexibility. Lockable steel doors are supplied as standard.Part No. SP Outgoing WaysTP Outgoing WaysMG6C6 18 6MG6C12 36 12MG6C18 54 18Powerpact 4 400A/630A Incoming DevicesFor cables greater than 240mm the use of a top/bottom extension box is recommended(Supplied separately to panelboard)Part No. Description Rating Bottom EntryPP44003X 3P MCCB 400 50kAPP44004X 4P MCCB 400 50kAPP44003NAX 3P Switch Disconnector 400APP44004NAX 4P Switch Disconnector 400APP46303X 3P MCCB 630A 50kAPP46304X 4P MCCB 630A 50kAPP46303NAX 3P Switch Disconnector 630APP46304NAX 4P Switch Disconnector 630A Top EntryPP42503TX 3P MCCB 250A 36kAPP42504TX 4P MCCB 250A 36kAPP42503NATX 3P Switch Disconnector 250APP42504NATX 4P Switch Disconnector 250APP44004TX 3P MCCB 400 50kAPP44004TX 4P MCCB 400 50kAPP44003NATX 3P Switch Disconnector 400APP44004NATX 4P Switch Disconnector 400APP46303TX 3P MCCB 630A 50kAPP46304TX 4P MCCB 630A 50kAPP46303NATX 3P Switch Disconnector 630APP46304NATX 4P Switch Disconnector 630ATop/bottom extension enclosures suitable for 250A, 400/630A and 800A Powerpact 4 panel boards providing extra space for cabling or metering.Part No. DescriptionMG6CEX Top/Bottom Extension EnclosureMG6CEXM Top/Bottom Meter Ready EnclosurePowerpact 4 Top/BottomExtensionsSP DP 3P 4P RatingPP40161* PP40162† PP40163X PP40164X 16A 25kAPP40251* PP40252† PP40253X PP40254X 25A 25kAPP40301* PP40302† PP40303X PP40304X 32A 25kAPP40401* PP40402† PP40403X PP40404X 40A 25kAPP40631* PP40632† PP40633X PP40634X 63A 25kAPP40801* PP40802† PP40803X PP40804X 80A 25kAPP41001* PP41002† PP41003X PP41004X 100A 25kAPP41251* PP41252† PP41253X PP41254X 125A 36kAPP41601* PP41602† PP41603X PP41604X 160A 36kA- - PP4P2003X PP42004X 200A 36kA- - PP42503X PP42504X 250A 36kA- - PP44003X PP44004X 400A 45kA- - PP46303X PP46304X 630A 45kA* Add suffix L1, L2, L3 when selecting single pole MCCBs. † Add suffix L1N, L2N, L3N, L12, L23, L31 when ordering double pole MCCBs.Full Range of accessories also available.Frame Only MCCBs*Frame OnlyPart No. 3PPart No. 4P RatingPP4 100A PP41003XFO 50KPP41004XFO 50K50kAPP4 160A PP41603XFO 50KPP41604XFO 50K50kAPP4 250A PP42503XFO 50KPP42504XFO 50K50kAPP4 400A PP44003XFO 50KPP44004XFO 50K50kAPP4 630A PP46303XFO 50KPP46304XFO 50K50kAPowerpact 4 MCCBOutgoing Devices* Trip units to be ordered separately.
