358INDUSTRIAL CONTROLSTogether we GENERATE VALUEABBPart No. Description1TVC230050P5699 DOL 5.5KW 230V Plastic 1TVC230070P5699 DOL 7.5KW 230V Plastic 1TVC400050P5699 DOL 5.5KW 400V Plastic 1TVC400070P5699 DOL 7.5KW 400V Plastic 1TVC230050S5699 DOL 5.5KW 230V Steel 1TVC230070S5699 DOL 7.5KW 230V Steel1TVC400050S5699 DOL 5.5KW 400V Steel 1TVC400070S5699 DOL 7.5KW 400V Steel1TVC230051S5699 DOL+ISO 5.5KW 230V Steel1TVC230071S5699 DOL+ISO 7.5KW 230V Steel1TVC400051S5699 DOL+ISO 5.5KW 400V Steel1TVC400071S5699 DOL+ISO 7.5KW 400V Steel1TVC230072S5699 DOLR 7.5KW 230V Steel1TVC400072S5699 DOLR 7.5KW 400V Steel1TVC230153S5699 SD 15.0KW 230V Steel1TVC230223S5699 SD 22.0KW 230V Steel1TVC400153S5699 SD415S 15.0KW 400V Steel1TVC400223S5699 SD 22.0KW 400V Steel1TVC230154S5699 SD+ISO 15.0KW 230V Steel1TVC230224S5699 SD+ISO 22.0KW 230V Steel1TVC400154S5699 SD+ISO 15.0KW 400V Steel1TVC400224S5699 SD+ISO 22.0KW 400V Steel• DOL and Start Delta Starters• Plastic Enclosure IP66 or Steel Enclosure IP55• No Overload fitted• Reversing DOL and Isolator Versions Motor StartersPart No. Description1SAZ721201R1023 Thermal Overload 0.74 ...1 A1SAZ721201R1025 Thermal Overload 1 ...1.3 A1SAZ721201R1028 Thermal Overload 1.3 ...1.7 A1SAZ721201R1031 Thermal Overload 1.7 ...2.3 A1SAZ721201R1033 Thermal Overload 2.3 ...3.1 A1SAZ721201R1035 Thermal Overload 3.1 ...4.2 A1SAZ721201R1038 Thermal Overload 4.2 ...5.7 A1SAZ721201R1040 Thermal Overload 5.7 ...7.6 A1SAZ721201R1043 Thermal Overload 7.6 ...10 A1SAZ721201R1045 Thermal Overload 10 ...13 A1SAZ721201R1047 Thermal Overload 13 ...16 A1SAZ721201R1049 Thermal Overload 16 ...20 A1SAZ721201R1051 Thermal Overload 20 ...24 A1SAZ721201R1052 Thermal Overload 24 ...29 A1SAZ721201R1053 Thermal Overload 29 ...35 A1SAZ721201R1055 Thermal Overload 35 ...38 A• Thermal Overloads for Starters • Note for Star Delta starters Overload setting should be 0.58 x FLCOverload for Motor StartersPart No. Description1TVC110000P3101 1 Way Start Pushbutton / Green1TVC101000P3102 1 Way Stop Pushbutton / Red1TVC101000P3203 Emergency Stop 30mm Twist Release1TVC101000P3204 Emergency Stop 40mm Twist Release1TVC101000P3205 Emergency Stop 60mm Twist Release1TVC101000P3206 Emergency Stop 40mm Key Release1TVC110000P3107 Two Position Switch1TVC110000P3108 Two Position Key Switch1TVC110100P3109 Three Position Switch1TVC110100P3110 Three Position Key Switch1TVC211000P3111 2 Way Start / Stop1TVC211000P3112 2 Way Start / E-StopPushbutton StationsPart No. Description1SFA611610R2001 Contact Block 1 Normally Open1SFA611610R2010 Contact Block 1 Normally ClosedContact BlocksMotor Starters
