68CABLE & ACCESSORIESTogether we GENERATE VALUE2-core/3-core & Earth BASEC CableNKT INSTAL%u00ae Type 6242*, 6243* - 2-Core/3-Core & Earth BASEC CableNKT INSTAL cables are designed for fixed installation, indoors, in air, in and under plaster. Installation of the product should only be carried out by personnel trained and qualified for electrical works. The product is designed according to recognised standards. Applicable rules of installation must be applied at all times. BS 7671 Current Edition recommandations on cable testing and comisioning must be followed during installation of the cables.Part No. Type Number of Cores Reel SizeVWY-210E10GRY Flat Grey 6242Y 2 x 1 Solid + 1 Solid 100mVWY-210E10GRY50M Flat Grey 6242Y 2 x 1 Solid + 1 Solid 50mVWY-215E10GRY Flat Grey 6242Y 2 x 1.5 Solid + 1 Solid 100mVWY-215E10GRY50M Flat Grey 6242Y 2 x 1.5 Solid + 1 Solid 50mVWY-225E15GRY Flat Grey 6242Y 2 x 2.5 Solid + 1.5 Solid 100mVWY-225E15GRY50M Flat Grey 6242Y 2 x 2.5 Solid + 1.5 Solid 50mVWY-S240E15GRY Flat Grey 6242Y 2 x 4.0 Stranded + 1.5 Solid 100mVWY-S240E15GRY50M Flat Grey 6242Y 2 x 4.0 Stranded + 1.5 Solid 50mVWY-S260E25GRY Flat Grey 6242Y 2 x 6.0 Stranded + 2.5 Solid 100mVWY-S260E25GRY50M Flat Grey 6242Y 2 x 6.0 Stranded + 2.5 Solid 50mVWY-S2100ES40GRY Flat Grey 6242Y 2 x 10.0 Stranded + 4.0 Stranded100mVWY-S2100ES40GRY50M Flat Grey 6243Y 2 x 10.0 Stranded + 4.0 Stranded50mVWY-310E10GRY Flat Grey 6243Y 3 x 1 Solid + 1 Solid 100mVWY-310E10GRY50M Flat Grey 6243Y 3 x 1 Solid + 1 Solid 50mVWY-315E10EGRY Flat Grey 6243Y 3 x 1.5 Solid + 1 Solid 100mVWY-315E10GRY50M Flat Grey 6243Y 3 x 1.5 Solid + 1 Solid 50mVWY-325E15GRY Flat Grey 6243Y 3 x 2.5 Solid + 1.5 Solid 100mVWY-325E15GRY50M Flat Grey 6243Y 3 x 2.5 Solid + 1.5 Solid 50mType 6242Y, 6243Y - PVCPart No. Type Number of Cores Reel SizeVWB-2100E10GRY Flat White 6242B 2 x 1 Solid + 1 Solid 100mVWB-215E10GRY Flat White 6242B 2 x 1.5 Solid + 1 Solid 100mVWB-225E15GRY Flat White 6242B 2 x 2.5 Solid + 1.5 Solid 100mVWB-S240E15GRY Flat White 6242B 2 x 4.0 Stranded + 1.5 Solid 100mVWB-S260E25GRY Flat White 6242B 2 x 6.0 Stranded + 2.5 Solid 100mVWB-S200ES40GRY Flat White 6242B 2 x 10.0 Stranded + 4.0 Stranded100mVWB-310E10GRY Flat White 6243B 3 x 1 Solid + 1 Solid 100mVWB-315E10EGRY Flat White 6243B 3 x 1.5 Solid + 1 Solid 100mVWB-325E15GRY Flat White 6243B 3 x 2.5 Solid + 1.5 Solid 100mType 6242B, 6243B - LSZHRated voltage 300/500 VTest voltage 2,5 kVMax. operating conductor temperature (PVC)+70%u00b0C(LSZH)+90%u00b0CMax. short-circuit temperature (PVC) +160 %u00b0C(LSZH) +250 %u00b0CTemperature range for handling (PVC)-40 %u00b0C up to +70 %u00b0CLSZH)-40 %u00b0C up to +90 %u00b0CMin. temperature for laying and manipulation -5%u00b0CColour of insulation Brown, blue in 2+EBrown, black, grey in 3+EMin. storage temperature -40%u00b0CUV stability NoMin. bending radius 4xd (Flat dimension)Packaging Cardboard ReelCertificate BASECCPR class Eca (DOP000916 - PVC)Dca (DOP000919 %u2013 LSZH)BS EN 50575 DOP000916 & DOP000919 YesRoHS YesREACH YesCE & UKCA DOP000916 & DOP000919 Yesecommandations on cable nd comisioning must be during installation of the The product is designed g to recognised standards. le rules of installation must ed at all times. Cert/LPCB ref.:Licence No: 246/001 & 246/002Type 6242B, 6243B - LSZH, CPR DcaType 6242Y, 6243Y - PVC, CPR EcaType 6242B, 6243B - LSZH, CPR Dca
