66CABLE & ACCESSORIESTogether we GENERATE VALUEFire Performance CableNOBURN Platinum Standard Fire Performance CablePart No. Conductor Size Number of Cores Reel SizeVFP-215ERD 1.5mm 2 Core & CPC 100mVFP-315ERD 1.5mm 3 Core & CPC 100mVFP-415ERD 1.5mm 4 Core & CPC 100mVFP-225ERD 2.5mm 2 Core & CPC 100mVFP-325ERD 2.5mm 3 Core & CPC 100mVFP-425ERD 2.5mm 4 Core & CPC 100mVFP-S240ERD 4.0mm 2 Core & CPC 100mVFP-S340ERD 4.0mm 3 Core & CPC 100mVFP-S440ERD 4.0mm 4 Core & CPC 100mWorking Voltage Core to Core 500VCore to CPC 300VResistance 1.0mm%u00b2 CSA 18.1 Ohms / 1 Km1.5mm%u00b2 CSA 12.1 Ohms / 1 Km2.5mm%u00b2 CSA 7.41 Ohms / 1 Km4.0mm%u00b2 CSA 4.61 Ohms / 1 KmMinimum Bend Radius Radius = 6 x DiameterOperating Temp. Minimum/Maximum - 40%u00b0C to +90%u00b0CInstallation Temp. Minimum/Maximum 0%u00b0C to +70%u00b0CVoltage Drop 1.0mm%u00b2 CSA 44 Ohms mV / A / m(DC or Single Phase AC) 1.5mm%u00b2 CSA 29 Ohms mV / A / m2.5mm%u00b2 CSA 18 Ohms mV / A / m4.0mm%u00b2 CSA 11 Ohms mV / A / mApproximate 2 Core 1.0mm%u00b2 / 7.75mmOverall Diameter 1.5mm%u00b2 / 7.85mm2.5mm%u00b2 / 9.20mm4.0mm%u00b2 / 11.90mm3 Core 1.5mm%u00b2 / 8.80mm2.5mm%u00b2 / 9.70mm4.0mm%u00b2 / 12.60mm4 Core 1.5mm%u00b2 / 9.40mm2.5mm%u00b2 / 11.60mm4.0mm%u00b2 / 13.75mmPart No. Conductor Size Number of Cores Reel SizeVFP-215EWT 1.5mm 2 Core & CPC 100mVFP-315EWT 1.5mm 3 Core & CPC 100mVFP-415EWT 1.5mm 4 Core & CPC 100mVFP-225EWT 2.5mm 2 Core & CPC 100mVFP-325EWT 2.5mm 3 Core & CPC 100mVFP-425EWT 2.5mm 4 Core & CPC 100mVFP-S240EWT 4.0mm 2 Core & CPC 100mVFP-S340EWT 4.0mm 3 Core & CPC 100mVFP-S440EWT 4.0mm 4 Core & CPC 100mPart No. Conductor Size Number of Cores Reel SizeVFP-215EBK 1.5mm 2 Core & CPC 100mNOBURN Platinum - Standard 60 Fire Cable - Red Sheath NOBURN Platinum - Standard 60 Fire Cable - White SheathNOBURN Platinum - Standard 60 Fire Cable - Black SheathPart No. Conductor Size Number of Cores Reel SizeVNP-215ERD 1.5mm 2 Core & CPC 100mVNP-315ERD 1.5mm 3 Core & CPC 100mVNP-415ERD 1.5mm 4 Core & CPC 100mVNP-225ERD 2.5mm 2 Core & CPC 100mVNP-325ERD 2.5mm 3 Core & CPC 100mVNP-425ERD 2.5mm 4 Core & CPC 100mVNP-S240ERD 4.0mm 2 Core & CPC 100mVNP-S340ERD 4.0mm 3 Core & CPC 100mVNP-S440ERD 4.0mm 4 Core & CPC 100mPart No. Conductor Size Number of Cores Reel SizeVNP-215EWT 1.5mm 2 Core & CPC 100mVNP-315EWT 1.5mm 3 Core & CPC 100mVNP-415EWT 1.5mm 4 Core & CPC 100mVNP-225EWT 2.5mm 2 Core & CPC 100mVNP-325EWT 2.5mm 3 Core & CPC 100mVNP-425EWT 2.5mm 4 Core & CPC 100mVNP-S240EWT 4.0mm 2 Core & CPC 100mVNP-S340EWT 4.0mm 3 Core & CPC 100mVNP-S440EWT 4.0mm 4 Core & CPC 100mNOBURN Plus - Enhanced 120 Fire Cable - Red Sheath NOBURN Plus - Enhanced 120 Fire Cable - White SheathNOBURN Plus Enhanced Fire Performance Cable
