                    CABLE & ACCESSORIES Fire Performance Cable
NoBurn Platinum Fire Performance Cable
    Working Voltage Resistance
Minimum Bend Radius
Operating Temp. Installation Temp.
Voltage Drop
(DC or Single Phase AC)
Approximate Overall Diameter
Current Rating
(Current Ratings listed are at 30°C Refer to BS7671/EE Wiring Regulations for de-rating factor.)
Capacitance Rating
Core to Core Core to CPC
1.0mm2 CSA 1.5mm2 CSA 2.5mm2 CSA 4.0mm2 CSA
Radius = 6 x Diameter
Minimum/Maximum Minimum/Maximum
1.0mm2 CSA 1.5mm2 CSA 2.5mm2 CSA 4.0mm2 CSA
2 Core
3 Core 4 Core
Cable Clipped
(DC or Single Phase AC)
Enclosed
(DC or Single Phase AC)
1.5mm2 CSA
2 Core & CPC 3 Core & CPC 4 Core & CPC ~
2.5mm2 CSA
2 Core & CPC 3 Core & CPC 4 Core & CPC ~
500V 300V
18.1 Ohms / 1 Km 12.1 Ohms / 1 Km 7.41 Ohms / 1 Km 4.61 Ohms / 1 Km
- 40°C to +90°C 0°C to +70°C
44 Ohms mV / A / m 29 Ohms mV / A / m 18 Ohms mV / A / m 11 Ohms mV / A / m
1.0mm2 / 7.75mm 1.5mm2 / 7.85mm 2.5mm2 / 9.20mm 4.0mm2 / 11.90mm 1.5mm2 / 8.80mm 2.5mm2 / 9.70mm 4.0mm2 / 12.60mm 1.5mm2 / 9.40mm 2.5mm2 / 11.60mm 4.0mm2 / 13.75mm
1.0mm2 15A 1.5mm2 19.5A 2.5mm2 27A 4.0mm2 36A 1.0mm2 13A 1.5mm2 16.5A 2.5mm2 23A 4.0mm2 30A
Core to Core - Average 70 pF/m Core to Screen - Average 130 pF/m Core to Core - Average 75 pF/m Core to Screen - Average 150 pF/m
Core to Core - Average 80 pF/m Core to Screen - Average 145 pF/m Core to Core - Average 85 pF/m Core to Screen - Average 165 pF/m
NoBurn Platinum - Standard 60 Fire Cable - White Sheath
        NoBurn Platinum - Standard 60 Fire Cable - Red Sheath
Part No. Conductor Size Number of Cores Reel Size
  VFP-215ERD
 1.5mm
 2 Core & CPC
 100m
 VFP-315ERD
  1.5mm
  3 Core & CPC
  100m
 VFP-415ERD
1.5mm
4 Core & CPC
100m
 VFP-225ERD
 2.5mm
 2 Core & CPC
 100m
 VFP-325ERD
 2.5mm
 3 Core & CPC
 100m
 VFP-425ERD
  2.5mm
  4 Core & CPC
  100m
 VFP-S240ERD
4.0mm
2 Core & CPC
100m
 VFP-S340ERD
  4.0mm
  3 Core & CPC
  100m
 VFP-S440ERD
 4.0mm
 4 Core & CPC
 100m
  Part No. Conductor Size Number of Cores Reel Size
  VFP-215EWT
 1.5mm
 2 Core & CPC
 100m
 VFP-315EWT
  1.5mm
  3 Core & CPC
  100m
 VFP-415EWT
1.5mm
4 Core & CPC
100m
 VFP-225EWT
 2.5mm
 2 Core & CPC
 100m
 VFP-325EWT
 2.5mm
 3 Core & CPC
 100m
 VFP-425EWT
  2.5mm
  4 Core & CPC
  100m
 VFP-S240EWT
4.0mm
2 Core & CPC
100m
 VFP-S340EWT
  4.0mm
  3 Core & CPC
  100m
 VFP-S440EWT
 4.0mm
 4 Core & CPC
 100m
    NoBurn Platinum - Standard 60 Fire Cable - Black Sheath
GENERATE VALUE
67
Part No. Conductor Size Number of Cores Reel Size
    VFP-215EBK 1.5mm 2 Core & CPC 100m
