                    CABLE & ACCESSORIES
Glands, Inserts & Gels
Plastic Tail Kits
• Protection class - IP68 / IP68 (5 bar 30 mins)
• 18th Edition Compliant
• Glow wire test - 750 °C
• Temperature range -40°C - 100°C
• Material - Polyamide, Gasket EPDM
Mini Gel Box
• Pre-filled gel junction box • IPX8
• 3-way entries
• No expiry date
• Non-toxic
• Re-enterable
• Immediate use
• Suitable for lever connectors
       Part No. Colour Type Size (mm)
  MBX01
  Grey
  Mini Gel Box 1
  36 x 33 x 24
 MBX02
 Grey
 Mini Gel Box 2
 43 x 33 x 24
 MBX03
 Grey
 Mini Gel Box 3
 57 x 33 x 24
   Part No. Gland Width Insert Suitable for No. of (mm) Tails/Earth Cores
Plastic Tails Kit, ESKV Cable Glands with: Multiple Insert, Locknut and Blind Plug
A.C.E COMBI Kit
   Junction Box with Earthing
  The WISKA A.C.E. COMBI kit (Armoured Cable Earthing) is the perfect solution for quick and effective termination of SWA cables.
Offering an effortless solution, with no drilling of the enclosure, pre-threaded entries, ready mounted terminal block, and a brass earthing clamp.
It allows a simple, quick and secure connection of the cables without the need of further drilling for the earth tag, allowing you to maintain the full IP rating of the enclosure.
• Kit contains...
• 1 x COMBI 308 Junction Box
• 1 x 5-pole terminal block
• 1 x EC308 earth bar
cCoommbbii
      TKE/P 32
TKE/P 40
ESKV 32
ESKV 40
13 - 21
16 - 28
MFD
    MFD
2 x 16mm / 1 x 16mm
2 x 25mm / 1 x 16mm
3
  3
      Plastic Tails Kit, ESKV Cable Glands with: Multiple Insert, Locknut, Blind Plug and Reducer
     TKE/P 40/RD
ESKV 40
16 - 28
MFD
2 x 25mm /1 x 16mm
3
     Plastic Tails Kit, ESKV Cable Glands with: Flat Insert and Locknut
     TKE/P 20/ FFD/1-1.5
ESKV 20
7.5 - 14
FFD
1 - 1.5 mm Flat Cable
1
     TKE/P 20/ FFD/2x1.5
TKE/P 20/ FFD/2.5-4
ESKV 20
ESKV 20
7.5 - 14
FFD
     7.5 - 14
FFD
2 x 1.5 mm Flat Cable
2.5 - 4 mm Flat Cable
2
 1
     TKE/P 25/FFD/6
ESKV 25
ESKV 25
9 - 17
9 - 17
FFD
   FFD
1 x 6 mm Flat Cable
1
  TKE/P 25/ FFD/02/2.5
2
   TKE/P 32/ FFD/10-16
ESKV 32
13 - 21
FFD
2 x 2.5 mm Flat Cable
  10 - 16 mm Flat Cable
1
        Brass Tail Kits
• Protection class - IP68 / IP68 (5 bar 30 mins)
• 18th Edition Compliant
• Temperature range -40°C - 100°C
• Material - Screw Brass nickel-plated, Clamping
cage Polyamide, Gasket EPDM
A.C.E COMBI Kit 308/5/EC/G 308/5/EC/B 308/5/EC/W 85 x 85 x 51
Junction Box with Gel Combi IP68
Set complete with MPGel and Stop End
• Kit contains...
• 1 x COMBI 308 Junction Box
• 1 x MP0030W MPGel
• 1 x Stop End
       Part No.
Gland
Width (mm)
Insert
Suitable for Tails/Earth
No. of Cores
Part No. Light Grey Black White LxBxH (mm)
    Part No. Light Grey
Part No. Black
  COMBI IP68 Set 308/5
400V 32A - 8 x 20mm Threaded Entries
Part No. White
Cable Width
LxBxH (mm)
             TKE/B 32
EMSKV 32
13 - 21
MFD
2 x 16mm / 1 x 16mm
3
      TKE/B 40
EMSKV 40
16 - 28
MFD
2 x 16mm / 1 x 16mm
3
EC66634 EC66634B - - 160 x 140 x 81
