                    CABLE & ACCESSORIES
Insulated Joints
Smart SHARK
• Pre-filled gel joint, no mixing or pouring
• Material - Polyamide
• Filling - Silicone gel
• Temperature range -20°C - 90°C
• Glow wire test - Self-extinguishing
• Voltage - 0.6 kV - 1 kV
• Blue
• Terminal block included
shark
    Part No.
Description
No. of Cores
Amp
LxBxH (mm)
 SHARK 315W
 Pre-filled Gel Insulation Joint
 3
5
 40 x 72 x 23
 SHARK 325W
 Pre-filled Gel Insulation Joint
 3
6
 47 x 86 x 27
 SHARK 310W
  Pre-filled Gel Insulation Joint
  3
 13
 55 x 146 x 35
 SHARK 316W
 Pre-filled Gel Insulation Joint
 3
 30
69 x 180 x 40
    SHARK Classic Series
• Pre-filled gel joint, no mixing or pouring
• Material - Polyamide
• Filling - Silicone gel
• Temperature range -20°C - 90°C
• Glow wire test - Self-extinguishing
• Voltage - 0.6 kV - 1 kV
• Blue
• Terminal block, earth braid and spring coil included
• Complies with EN50393 for underground joints
SHARK SixEight
• Pre-filled gel joint, no mixing or pouring
• Protection class - IP68 (up to 10 metres)
• Material - Polyamide
• Filling - Silicone gel
• Temperature range -20°C - 90°C
• Glow wire test Self-extinguishing
• Voltage - 0.6 kV - 1 kV
• Blue
• Terminal block, earth braid and spring coil included
sixeight
    Part No.
 Description
 No. of Cores
 Amp
Width (mm)
LxBxH (mm)
 SHARK 506W
 Pre-filled Gel Insulation Joint
 5
 80
1.5 - 6
55 x 146 x 35
 SHARK 525W
 Pre-filled Gel Insulation Joint
 3 4 5
 135
2.5 - 16 2.5 - 16 2.5 - 10
69 x 180 x 40
      Part No.
 Description
 Connector Type
 No. of Cores
Amp
Width (mm)
LxBxH (mm)
SHARK 6801 BW
Pre-filled Gel Insulation Joint
3 Pole Strip connector
3
32
2.5 - 6
190 x 60 x 48
 SHARK 6801 DW
 Pre-filled Gel Insulation Joint
 5 x Crimp Connectors
5
41
2.5 - 6
190 x 60 x 48
 SHARK 6802 AW
  Pre-filled Gel Insulation Joint
  5 Pole Terminal Block
 5
80
2.5 - 10
235 x 68 x 48
SHARK 6803 AW
 Pre-filled Gel Insulation Joint
 5 Pole Terminal Block
 5
135
10 - 25
310 x 85 x 60
