                    CABLE & ACCESSORIES Brace System
 IP68 Flexible Conduit Fittings - Plastic
IP68 flexible conduit fitting Polyamide plastic Intergrated strain relief UL94-V0
Flexible Conduit - PA6 Plastic
      • • • •
• BraceCONDUIT - BCA-S V0
• Polyamide PA6, UL94-V0,
temperature range -40˚C - 140˚C
     Part No.
Type
Colour
Diameter Inner/Outer (mm)
Size (mm)
 10109175
  BCA-S-07
  Black
  7 / 10
  50
 10107072
BCA-S-10
Black
10 / 13
50
 10107073
 BCA-S-12
 Black
 12 / 15.7
 50
 10107074
 BCA-S-14
 Black
 14 / 18.5
 50
 10107075
 BCA-S-17
 Black
 17 / 21.2
 50
 10107076
  BCA-S-23
  Black
  23 / 28.3
  50
 10107077
BCA-S-29
Black
29 / 34.5
25
 10107078
  BCA-S-36
  Black
  36 / 42.2
  25
   Part No.
Type
Colour
Size
Inner Diameter (mm)
 10106861
 EBFS-07-12
 Black
 M12
 7
 10106862
 EBFS-10-12
 Black
 M12
 10
 10106863
  EBFS-10-16
  Black
  M16
  10
 10106864
EBFS-12-16
Black
M16
12
 10106865
 EBFS-12-20
 Black
 M20
 12
 10106866
 EBFS-14-20
 Black
 M20
 14
 10106867
 EBFS-17-20
 Black
 M20
 17
 10106868
  EBFS-17-25
  Black
  M25
  17
 10106869
 EBFS-23-25
 Black
 M25
 23
 10106870 10106871 10106872 10106873
EBFS-23-32 EBFS-29-32 EBFS-29-40 EBFS-36-40
Black Black Black Black
M32 M32 M40 M40
23 29 29 36
 10106874
 EBFS-36-50
 Black
 M50
 36
 10106875
  EBFS-48-50
  Black
  M50
  48
 10106876
 EBFS-48-63
 Black
 M63
 48
    10109176
BCA-S-48
Black
48 / 54.5 25
       • •
IP68 Flexible Conduit Kits - Plastic
BraceCONTRACTOR Kits - BC Kit 1
Kit includes:
1m flexible conduit (BCAB-L 17),
2 x BraceFITTING M20 (EBFS 17-20),
1 x COMBI 206,
1 x M20 cable gland (ESKV 20+),
1 x M20 locknut (EMUG)
IP68 Flexible Conduit Kits - Plastic
BraceCONTRACTOR Kits - BC Kit 2
Kit includes:
10m flexible conduit (BCAB-L 17),
10 x BraceFITTING M20 (EBFS 17-20),
2 x COMBI 406,
10 x M20 locknut (EMUG)
• •
• •
• •
IP68 Flexible Conduit Kits - Plastic
BraceCONTRACTOR Kits - BC Kit 3
Kit includes:
10m flexible conduit (BCAB-L 23),
10 x BraceFITTING M25 (EBFS 25),
2 x COMBI 607,
10 x M25 locknut (EMUG)
IP68 Flexible Conduit Kits - Plastic
BraceCONTRACTOR Kits - BC Kit 4
Kit includes:
10m flexible conduit (BCAB-L 17),
10 x BraceFITTING M20 (EBFS 17-20),
10 x M20 locknut (EMUG)
IP68 Flexible Conduit Kits - Plastic
BraceCONTRACTOR Kits - BC Kit 5
Kit includes:
10m flexible conduit (BCAB-L 123),
10 x BraceFITTING M25 (EBFS 25),
10 x M25 locknut (EMUG)
   Part No. Type Colour
   10110317 BC Kit 3 Black
       Part No. Type Colour
    10110226 BC Kit 1 Black
 • •
         Part No. Type Colour
Part No. Type Colour
10110230 BC Kit 4 Black
  Part No. Type Colour
   10110316 BC Kit 5 Black
    10110231 BC Kit 2 Black
