P. 76

                    CABLE MANAGEMENT Flexible Conduit
Flexible Conduit - Standard Weight
• Polyamide (Nylon) 6 Black
• Temp Range -40C to 120C
• StaticandDynamicApplications
• HighFlexibility–HighFatigueLife
• Self-Extinguishing, Halogen Free
Flexible Conduit - General Purpose
• Galvanised Steel
• Temp Range - 50c to 300c
• Highly Flexible
• High UV Resistance
Flexible Conduit - SP
• Liquid Resistant, General Purpose
• PVC Covered Galvanised Steel
• Temp Range - 25c to 70c
• Highly Flexible, High UV Resistance
• IP40
Flexible Conduit - SP
• Straight Fitting - Fixed & Swivel External Male Thread
• IP40
ABB
adaptaflex
   Part No. Nominal Conduit Size NW Conduit Size Conduit Pitch Outside Diameter Inside Diameter Static Bend Radius Reel Length
  PAFS21BL10M
  21mm
  17
  Fine
  21.2mm
  16.5mm
  45mm
  10 Meters
 PAFS21BL25M
21mm
17
Fine
21.2mm
16.5mm
45mm
25 Meters
 PAFS21BL50M
 21mm
 17
 Fine
 21.2mm
 16.5mm
 45mm
 50 Meters
 PAFS28BL10M
 28mm
 23
 Fine
 28.5mm
 22.6mm
 50mm
 10 Meters
 PAFS28BL25M
  28mm
  23
  Fine
  28.5mm
  22.6mm
  50mm
  25 Meters
 PAFS28BL50M
 28mm
 23
 Fine
 28.5mm
 22.6mm
 50mm
 50 Meters
      Part No. Nominal Conduit Size Conduit Pitch Outside Diameter Inside Diameter Static Bend Radius Reel Length
  S20/10M
 20mm
 Fine
 20.5mm
 16.9mm
 45mm
 10 Meters
 S20/25M
 20mm
 Fine
 20.5mm
 16.9mm
 45mm
 25 Meters
 S20/50M
 20mm
 Fine
 20.5mm
 16.9mm
 45mm
 50 Meters
 S25/10M
  25mm
  Fine
  25.0mm
  21.4mm
  55mm
  10 Meters
 S25/25M
 25mm
 Fine
 25.0mm
 21.4mm
 55mm
 25 Meters
 S25/50M
 25mm
 Fine
 25.0mm
 21.4mm
 55mm
 50 Meters
      Part No. Conduit Nominal Conduit Size Outside Diameter Inside Diameter Static Bend Radius Reel Length
  SP20BL10M
 1/2 Inch
 20
 21.5mm
 16.9mm
 45mm
 10 Meters
 SP20BL25M
 1/2 Inch
 20
 21.5mm
 16.9mm
 45mm
 25 Meters
 SP20BL50M
  1/2 Inch
  20
  21.5mm
  16.9mm
  45mm
  50 Meters
 SP25BL10M
3/4 Inch
25
26.0mm
21.4mm
55mm
10 Meters
 SP25BL25M
  3/4 Inch
  25
  26.0mm
  21.4mm
  55mm
  25 Meters
 SP25BL50M
 3/4 Inch
 25
 26.0mm
 21.4mm
 55mm
 50 Meters
       Part No. Conduit Fitting Metric Thread
  SP20M20A
 1/2 Inch
 Fixed
 M20
 SP20M20B
 1/2 Inch
 Swivel
 M20
 SP25M25A
    Fixed
  M25
 SP25M25B
 3/4 Inch
 Swivel
 M25
    76
