79CABLE MANAGEMENTTogether we GENERATE VALUETrunking & Lighting TrunkingEnd Cap Pre-GalvPart No. Width HeightACT-EC22/PG 50mm 50mmACT-EC33/PG 75mm 75mmACT-EC42/PG 100mm 50mmACT-EC44/PG 100mm 100mmACT-EC66/PG 150mm 150mmACT-ECSuspension Hanger Pre-GalvPart No. Width HeightACT-SH22/PG 50mm 50mmACT-SH33/PG 75mm 75mmACT-SH42/PG 100mm 50mmACT-SH44/PG 100mm 100mmACT-SH66/PG 150mm 150mmACT-SHFlared Reducer Pre-GalvPart No. Width HeightATB-FLR33-22/PG 75 x 75mm 50 x 50mmATB-FLR44-22/PG 100 x 100mm 50 x 50mmATB-FLR44-33/PG 100 x 100mm 75 x 75mmATB-FLR66-44/PG 150 x 150mm 100 x 100mmATB-FLRTrunkingGusset Intersection Top Lid Pre-GalvPart No. Width HeightATB-GIT22/PG 50mm 50mmATB-GIT33/PG 75mm 75mmATB-GIT42/PG 100mm 50mmATB-GIT44/PG 100mm 100mmATB-GIT66/PG 150mm 150mmATB-GITLighting TrunkingPart No. Description Width HeightASG55/3 3m Body Length 50mm 50mmASG55/5 5m Body Length 50mm 50mmAPCW/2 2m Lid Length - Plastic 50mm -ASCG 2m Lid Length - Galv 50mm -ALCC55 Straight Coupler (Each) 50mm 50mmA2WC55 Horizontal 90° Bend 50mm 50mmA2WC55/45 Horizontal 45° Bend 50mm 50mmADBC55 Internal 90° Bend 50mm 50mmPart No. Description Width HeightARBC55 External 90° Bend 50mm 50mmA3WC55 Horizontal Tee 50mm 50mmA4WC55 Horizontal Intersection 50mm 50mmAEP55 End Plate 50mm 50mmAFEP55 Flanged End Plate 50mm 50mmASSB55/10 Stirrup Hanger C/W 10.5mm Hole 50mm 50mmABSS Bush Suspension Set 50mm 50mmACR55 Cable Retainer 50mm -Lighting Trunking Length White Plastic Capping 2m Galvanised Capping 2m Straight Connector
